Product Description
Checking fixture will ensure that the following apply to all fixtures:
Are produced in a timely manner to meet program timing objectives, including OEM Specific requirements where applicable.
Agree with functional part usage.
Comply with part Geometric Dimensioning and Tolerancing (GD&T) by honoring the datum scheme.
Must include the measurement of all Key Product Characteristics (KPC’s), and Special Characteristics (SC’s).
Variable data collection devices are required for all KPCs, and SCs.
For KPCs and SCs, these variable data collection devices must be hard attached to the fixture / gages, and be capable of meeting all AIAG Measurement Systems Analysis (MSA) requirements.
Our production detail
| Items | ||
| 1 | Base Material | Al |
| 2 | Application | Stamping Parts |
| 3 | Surface treatment | Oxidation |
| 4 | Processing Precision | 0.15 |
| 5 | Accuracy for Other Profiles | 0.1 |
| 6 | Accuracy for Datum Hole | ±0.05 |
| 7 | Certificate | ISO 9001:2008 |
| 8 | CMM certification | Yes |
| 9 | Software | Catia, UG, CAD, STP |
| 10 | Specification | 480*360*280mm |
| 11 | Packing | Wooden Box |
Manufacturing tolerance:
1.The Flatness of Base Plate 0.05/1000
2.The Thickness of Base Plate ±0.03mm
3.The Location Datum ±0.02mm
4.The Surface ±0.1mm
5.The Checking Pins and Holes ±0.1mm
Process
CNC Machining(Milling/Turning), Grinding
Electroplating Chromium Treatment
Quality Control
CMM (3D Coordinate Measuring Machine), Vms-2515G 2D Projector, HR-150 A Hardness Tester
Third Party Certification done by ShenZhen Silver Basis Testing Technology Co., Ltd , ISO17025 Certified
Lead time & Packing
35 days after 3D design approved
7 days via express: FedEx
Standard Export Wooden Case
Primary Competitive Advantages
Pursuit Of Quality Excellence
Multiple Products & Services
Efficiency Consciousness-On-Time Delivery
Cost Consciousness-Innovative Design Solutions To Reduce The Cost
Timely Communication With Our Customer
Compliance With Cooperator’s Terms And Conditions
NDA(Non-disclosure Agreement)
Our purpose is that we can only succeed if our customers succeed.
